 Construction: manufactured in stainless steel 18/10.
Diameter of wheel: 230 mm
Band length: 1750 mm
Cutting height: 175 mm
Cutting thickness: 200 mm

Motors:
Three phase of 1.5 HP / 0,92 & 1,10 kW (230-400V 50Hz / 220V 60Hz)
Single phase of 1.5 HP / 1,10 kW (230V 50Hz / 220V 60 Hz)

The standard model features: manual band tensioner, thickness adjustment stopper and hinged pusher with fixed intermediate guide of the band.


 Construction: manufactured in stainless steel 18/10.
Wheel diameter: 275 mm
Band length: 2280 mm
Cutting height: 310 mm
Cutting thickness: 233 mm

Motors:
Three phase of  2 or 3 HP / 1,5 or 2.2 kW (230-400V 50Hz / 220V 60Hz)
Single phase of 1.5 HP / 1,10 kW (230V 50Hz / 220V 60 Hz)

The standard model features: manual band tensioner, thickness adjustment stopper and hinged pusher with adjustable intermediate guide of the band.


 Construction: manufactured in stainless steel 18/10.
Diameter of wheel: 300 mm
Band length: 2720 mm
Cutting height: 352 mm
Cutting thickness: 280 mm

Motors:
Three phase of 3 HP / 2,2 kW (230-400V 50Hz / 220V 60Hz)
Single phase of 2.5 HP / 1,84 kW (230V 50Hz / 220V 60 Hz)

The standard model features: automatic band tensioner, thickness adjustment stopper, hinged pusher with adjustable intermediate guide of the band, waste box and cooling fan kit.


BC-3200 JV: Model with column on the left.
BC-3200 LHS: Model with column on the right.

Construction: manufactured in stainless steel 18/10.
Diameter of wheel: 330 mm
Band length: 3060 mm
Cutting height: 400 mm
Cutting thickness: 310 mm

Motors:
Three phase of 4 HP / 2,9 kW (230-400V 50Hz / 220V 60Hz)
Single phase of 3.5 HP / 2,6 kW (230V 50Hz / 220V 60 Hz)

The standard model features: automatic band tensioner, thickness adjustment stopper, hinged pusher with adjustable intermediate guide of the band, waste box, cooling fan kit and fixed table with discharge ramp.
